上一篇學習了pcache1的機制，這是pagecache管理的一個插件，在這基礎上又封裝了一層，主要是用來處理臟頁(就是修改過的緩存頁)，如臟頁的添加刪除和回收利用等，這部分代碼的實現在pcache.c里。

1.數據結構

在pcache中，通過PCache結構對象作為連接句柄，每個緩存頁通過PgHdr來表示。

在pagecache中，所有的臟頁通過一個雙向鏈表來連接在一起，其結構關系如下圖所示：

   其中pCache->pDirty為鏈表的頭部，pCache->pDirtyTail為鏈表的尾部。

2.臟頁的添加和刪除

這個鏈表是按照LRU的順序來維護的，新的鏈表元素是從頭部插入，即頁面p比p->DirtyNext更新。pCache->pDirty指向最新的頁面，pCache->pDirtyTail指向最老的頁面。

鏈表的插入和刪除由pcacheManageDirtyList()函數來完成

/* Allowed values for second argument to pcacheManageDirtyList() */
#define PCACHE_DIRTYLIST_REMOVE   1    /* Remove pPage from dirty list */
#define PCACHE_DIRTYLIST_ADD      2    /* Add pPage to the dirty list */
#define PCACHE_DIRTYLIST_FRONT    3    /* Move pPage to the front of the list */

/*
** Manage pPage's participation on the dirty list.  Bits of the addRemove
** argument determines what operation to do.  The 0x01 bit means first
** remove pPage from the dirty list.  The 0x02 means add pPage back to
** the dirty list.  Doing both moves pPage to the front of the dirty list.
*/
static void pcacheManageDirtyList(PgHdr *pPage, u8 addRemove){
  PCache *p = pPage->pCache;

  pcacheTrace(("%p.DIRTYLIST.%s %d\n", p,
                addRemove==1 ? "REMOVE" : addRemove==2 ? "ADD" : "FRONT",
                pPage->pgno));//打印調試信息
  //把頁面從鏈表移除
  if( addRemove & PCACHE_DIRTYLIST_REMOVE ){
    assert( pPage->pDirtyNext || pPage==p->pDirtyTail );
    assert( pPage->pDirtyPrev || pPage==p->pDirty );

/* Update the PCache1.pSynced variable if necessary. */
    if( p->pSynced==pPage ){
      p->pSynced = pPage->pDirtyPrev;
    }

    if( pPage->pDirtyNext ){
      pPage->pDirtyNext->pDirtyPrev = pPage->pDirtyPrev;//讓下一個節點指向前一個節點
    }else{
      assert( pPage==p->pDirtyTail );
      //如果被刪除的頁面是最后一個，那么更新鏈表尾部
      p->pDirtyTail = pPage->pDirtyPrev;
    }
if( pPage->pDirtyPrev ){
  //讓前一個節點指向后一個節點
      pPage->pDirtyPrev->pDirtyNext = pPage->pDirtyNext;
    }else{
      /* If there are now no dirty pages in the cache, set eCreate to 2.
      ** This is an optimization that allows sqlite3PcacheFetch() to skip
      ** searching for a dirty page to eject from the cache when it might
      ** otherwise have to.  */
      assert( pPage==p->pDirty );
      //如果被刪的是頭部，那么更新鏈表頭部
      p->pDirty = pPage->pDirtyNext;
      assert( p->bPurgeable || p->eCreate==2 );
      if( p->pDirty==0 ){         /*OPTIMIZATION-IF-TRUE*/
        assert( p->bPurgeable==0 || p->eCreate==1 );
        //沒有臟頁的情況下，p->eCreate被設為2
        p->eCreate = 2;
      }
    }
    pPage->pDirtyNext = 0;
    pPage->pDirtyPrev = 0;
  }
  //在鏈表頭部插入新的頁面
  if( addRemove & PCACHE_DIRTYLIST_ADD ){
    assert( pPage->pDirtyNext==0 && pPage->pDirtyPrev==0 && p->pDirty!=pPage );

    pPage->pDirtyNext = p->pDirty;
    if( pPage->pDirtyNext ){
      assert( pPage->pDirtyNext->pDirtyPrev==0 );
      //讓上一個節點指向下一個節點
      pPage->pDirtyNext->pDirtyPrev = pPage;
}else{
  //如果是第一個節點，那么添加尾部
      p->pDirtyTail = pPage;
      if( p->bPurgeable ){
        assert( p->eCreate==2 );
        //有臟頁存在時，p->eCreate置1
        p->eCreate = 1;
      }
}
    //更新鏈表頭部
    p->pDirty = pPage;

    /* If pSynced is NULL and this page has a clear NEED_SYNC flag, set
    ** pSynced to point to it. Checking the NEED_SYNC flag is an
    ** optimization, as if pSynced points to a page with the NEED_SYNC
    ** flag set sqlite3PcacheFetchStress() searches through all newer
    ** entries of the dirty-list for a page with NEED_SYNC clear anyway.  */
    if( !p->pSynced
     && 0==(pPage->flags&PGHDR_NEED_SYNC)   /*OPTIMIZATION-IF-FALSE*/
){
  // p->pSynced是一個標記頁，用來快速查找最新的已被同步的頁
      p->pSynced = pPage;
    }
  }
  pcacheDump(p);
}

3.頁面讀取

    讀取頁面的接口函數是sqlite3PcacheFetch(),在這個函數中需要通過sqlite3GlobalConfig.pcache2.xFetch()調用插件pcache1的接口，如果讀取的頁面不在緩存中時，由傳入的第3個參數eCreate來控制創建緩存頁的策略。

eCreate的真值又由createFlag和pCache->eCreate來決定，而pCache->eCreate的真值又由pCache->bPurgeable和pCache->pDirty來決定，真值表如下：

sqlite3_pcache_page *sqlite3PcacheFetch(
  PCache *pCache,       /* Obtain the page from this cache */
  Pgno pgno,            /* Page number to obtain */
  // createFlag傳入的值是0或3(即二進制11)
  int createFlag        /* If true, create page if it does not exist already */
){
  int eCreate;
  sqlite3_pcache_page *pRes;

  assert( pCache!=0 );
  assert( pCache->pCache!=0 );
  assert( createFlag==3 || createFlag==0 );
  //見第一個真值表第3行
  assert( pCache->eCreate==((pCache->bPurgeable && pCache->pDirty) ? 1 : 2) );
  //對于eCreate的具體處理見上一篇文章
  /* eCreate defines what to do if the page does not exist.
  **    0     Do not allocate a new page.  (createFlag==0)
  **    1     Allocate a new page if doing so is inexpensive.
  **          (createFlag==1 AND bPurgeable AND pDirty)
  **    2     Allocate a new page even it doing so is difficult.
  **          (createFlag==1 AND !(bPurgeable AND pDirty)
  */
  /*上面的注釋的意思是說如果cache slot可回收，并且存在臟頁的情況下，
  **如果緩存頁的數量達到最大時需要預留一些slot，不再回收或創建新的
  **緩存頁*/
  //見第2個真值表
  eCreate = createFlag & pCache->eCreate;
  assert( eCreate==0 || eCreate==1 || eCreate==2 );
  assert( createFlag==0 || pCache->eCreate==eCreate );
  //即eCreate==1+!(pCache->bPurgeable&&pCache->pDirty)
  //即bPurgeable和pDirty都滿足的情況下，eCreate是1
  assert( createFlag==0 || eCreate==1+(!pCache->bPurgeable||!pCache->pDirty) );
  pRes = sqlite3GlobalConfig.pcache2.xFetch(pCache->pCache, pgno, eCreate);
  pcacheTrace(("%p.FETCH %d%s (result: %p)\n",pCache,pgno,
               createFlag?" create":"",pRes));
  return pRes;
}

  取到的頁面是一個sqlite3_pcache_page類型的對象，由上篇文章知道PgHdr1是該類型的一個繼承。

  根據這個對象，調用sqlite3PcacheFetchFinish()來獲得PgHdr對象,并初始化,這里有個比較有意思的地方，就是sqlite3PcacheFetchFinish()調用pcacheFetchFinishWithInit()初始化后，間接地遞歸調用自己。

PgHdr *sqlite3PcacheFetchFinish(
  PCache *pCache,             /* Obtain the page from this cache */
  Pgno pgno,                  /* Page number obtained */
  sqlite3_pcache_page *pPage  /* Page obtained by prior PcacheFetch() call */
){
  PgHdr *pPgHdr;

  pPgHdr = (PgHdr *)pPage->pExtra;

  if( !pPgHdr->pPage ){
    return pcacheFetchFinishWithInit(pCache, pgno, pPage);
  }
  ……
  return pPgHdr;
}

static SQLITE_NOINLINE PgHdr *pcacheFetchFinishWithInit(
  PCache *pCache,             /* Obtain the page from this cache */
  Pgno pgno,                  /* Page number obtained */
  sqlite3_pcache_page *pPage  /* Page obtained by prior PcacheFetch() call */
){
  PgHdr *pPgHdr;
  assert( pPage!=0 );
  pPgHdr = (PgHdr*)pPage->pExtra;
  ……
  return sqlite3PcacheFetchFinish(pCache,pgno,pPage);
}

4.頁面讀取失敗后的處理

    如果頁面讀取失敗，那么說明頁緩存的數量已經超過最大值，那么找到一個已經sync的臟頁回收，如果沒找到，那么找一個最老的頁面來刷盤回收，但是如果還沒sync，通常還沒有獨占鎖，會返回一個busy。

回收一個臟頁后，不管成功沒成功都要為讀取失敗的頁面分配一個新的頁緩存，即把eCreate強制設為2。

/*
** If the sqlite3PcacheFetch() routine is unable to allocate a new
** page because no clean pages are available for reuse and the cache
** size limit has been reached, then this routine can be invoked to
** try harder to allocate a page.  This routine might invoke the stress
** callback to spill dirty pages to the journal.  It will then try to
** allocate the new page and will only fail to allocate a new page on
** an OOM error.
**
** This routine should be invoked only after sqlite3PcacheFetch() fails.
*/
int sqlite3PcacheFetchStress(
  PCache *pCache,                 /* Obtain the page from this cache */
  Pgno pgno,                      /* Page number to obtain */
  sqlite3_pcache_page **ppPage    /* Write result here */
){
  PgHdr *pPg;
  if( pCache->eCreate==2 ) return 0;
  // pCache->szSpill是設置的一個可回收的閾值
  if( sqlite3PcachePagecount(pCache)>pCache->szSpill ){
    /* Find a dirty page to write-out and recycle. First try to find a
    ** page that does not require a journal-sync (one with PGHDR_NEED_SYNC
    ** cleared), but if that is not possible settle for any other
    ** unreferenced dirty page.
    **
    ** If the LRU page in the dirty list that has a clear PGHDR_NEED_SYNC
    ** flag is currently referenced, then the following may leave pSynced
    ** set incorrectly (pointing to other than the LRU page with NEED_SYNC
    ** cleared). This is Ok, as pSynced is just an optimization.  */
   //首先從pCache->pSynced開始搜索已經sync的page
    for(pPg=pCache->pSynced;
        pPg && (pPg->nRef || (pPg->flags&PGHDR_NEED_SYNC));
        pPg=pPg->pDirtyPrev
    );
    //找到之后更新pCache->pSynced
    pCache->pSynced = pPg;
    //如果沒找到，那么就找一個沒有引用的頁
    if( !pPg ){
      for(pPg=pCache->pDirtyTail; pPg && pPg->nRef; pPg=pPg->pDirtyPrev);
    }
    if( pPg ){
      int rc;
#ifdef SQLITE_LOG_CACHE_SPILL
      sqlite3_log(SQLITE_FULL,
                  "spill page %d making room for %d - cache used: %d/%d",
                  pPg->pgno, pgno,
                  sqlite3GlobalConfig.pcache.xPagecount(pCache->pCache),
                numberOfCachePages(pCache));
#endif
      pcacheTrace(("%p.SPILL %d\n",pCache,pPg->pgno));
     // xStress和pStress由sqlite3PcacheOpen時傳入
     //該函數把臟頁刷到磁盤，并從臟頁鏈表中移除
      rc = pCache->xStress(pCache->pStress, pPg);
      pcacheDump(pCache);
    //如果沒有鎖資源，會返回SQLITE_BUSY
      if( rc!=SQLITE_OK && rc!=SQLITE_BUSY ){
        return rc;
      }
    }
  }
  //不管page數量是否超限，都創建一個新的緩存頁
  *ppPage = sqlite3GlobalConfig.pcache2.xFetch(pCache->pCache, pgno, 2);
  return *ppPage==0 ? SQLITE_NOMEM_BKPT : SQLITE_OK;
}

5.結束

關于page cache的內容，就基本講這么多吧，另外pcacheSortDirtyList()函數對臟頁按照頁號重新排序，這里用到了鏈表的歸并排序方法，將在下一篇文章中介紹，剩下的其他函數都是很容易理解的。

另外再提2個問題：

1.為什么只有存在臟頁的時候，讀取頁面的時候才設置page數量的最大值，即pCache->pDirty不為空的時候，eCreate的值才為1

2.sqlite3PcacheFetchStress()函數回收臟頁的時候，為什么要先找已經sync的page。

這2個問題單獨從page cache模塊中還沒看到答案，可能需要事務處理和日志模塊的相關知識，在以后對pager模塊完全理解透徹后再回過頭來看這2個問題。
