1.SVM

（1）這里我選擇懲罰系數$C=1$C=1做實驗，不同的懲罰系數$C$C可能導致結果不同。

• 核函數kernel.m

function K = kernel(X,Y,type,gamma)
    switch type
    case 'linear'   %線性核
        K = X*Y';
    case 'rbf'      %高斯核
        m = size(X,1);
        K = zeros(m,m);
        for i = 1:m
            for j = 1:m
                K(i,j) = exp(-gamma*norm(X(i,:)-Y(j,:))^2);
            end
        end
    end
end

• 訓練函數svmTrain.m

function svm = svmTrain(X,Y,kertype,gamma,C)
    %二次規劃問題，使用quadprog，詳細help quadprog
    n = length(Y);
    H = (Y*Y').*kernel(X,X,kertype,gamma);
    f = -ones(n,1);
    A = [];
    b = [];
    Aeq = Y';
    beq = 0;
    lb = zeros(n,1);
    ub = C*ones(n,1);
    a = quadprog(H,f,A,b,Aeq,beq,lb,ub);
    epsilon = 3e-5; %閾值可以根據自身需求選擇
    %找出支持向量
    svm_index = find(abs(a)> epsilon);
    svm.sva = a(svm_index);
    svm.Xsv = X(svm_index,:);
    svm.Ysv = Y(svm_index);
    svm.svnum = length(svm_index);
    svm.a = a;
end

• 預測函數predict1.m

function test = predict1(train_data_name,test_data_name,kertype,gamma,C)
    %(1)-------------------training data ready-------------------
    train_data = load(train_data_name);
    n = size(train_data,2); %data column
    train_x = train_data(:,1:n-1);
    train_y = train_data(:,n);
    %find the position of positive label and negtive label
    pos = find ( train_y == 1 );
    neg = find ( train_y == -1 );
    figure('Position',[400 400 1000 400]);
    subplot(1,2,1);
    plot(train_x(pos,1),train_x(pos,2),'k+');
    hold on;
    plot(train_x(neg,1),train_x(neg,2),'bs');
    hold on;

    %(2)-----------------decision boundary-------------------
    train_svm = svmTrain(train_x,train_y,kertype,gamma,C);
    %plot the support vector
    plot(train_svm.Xsv(:,1),train_svm.Xsv(:,2),'ro');
    train_a = train_svm.a;
    train_w = [sum(train_a.*train_y.*train_x(:,1));sum(train_a.*train_y.*train_x(:,2))];
    train_b = sum(train_svm.Ysv-train_svm.Xsv*train_w)/size(train_svm.Xsv,1);
    train_x_axis = 0:1:200;
    plot(train_x_axis,-train_b-train_w(1,1)*train_x_axis/train_w(2,1),'-');
    legend('1','-1','suport vector','decision boundary');
    title('training data')
    hold on;

    %(3)-------------------testing data ready----------------------
    test_data = load(test_data_name);
    m = size(test_data,2); %data column
    test_x = test_data(:,1:m-1);
    test_y = test_data(:,m);
    %find the test data positive label and negtive label
    test_label = sign(test_x*train_w + train_b);
    subplot(1,2,2);
    test_pos = find ( test_y == 1 );
    test_neg = find ( test_y == -1 );
    plot(test_x(test_pos,1),test_x(test_pos,2),'k+');
    hold on;
    plot(test_x(test_neg,1),test_x(test_neg,2),'bs');
    hold on;

    %(4)------------------decision boundary -----------------------
    test_x_axis = 0:1:200;
    plot(test_x_axis,-train_b-train_w(1,1)*test_x_axis/train_w(2,1),'-');
    legend('1','-1','decision boundary');
    title('testing data');
    %print the detail
    fprintf('--------------------------------------------\n');
    fprintf('training_data: %s\n',train_data_name);
    fprintf('testing_data: %s\n',test_data_name);
    fprintf('C = %d\n',C);
    fprintf('number of test data label: %d\n',size(test_data,1));
    fprintf('predict corret number of test data label: %d\n',length(find(test_label==test_y)));
    fprintf('Success rate: %.4f\n',length(find(test_label==test_y))/size(test_data,1));
    fprintf('--------------------------------------------\n');
end

• 主函數part1.m

kertype = 'linear';
gamma = 0;  C = 1;
predict1('training_1.txt','test_1.txt',kertype,gamma,C);
predict1('training_2.txt','test_2.txt',kertype,gamma,C);

做出圖像如下

• training_1.txt 和 test_1.txt

• training_2.txt 和 test_2.txt

  （2）測試數據的預測結果如下，可以由上面第(1)問中的代碼獲得

training_data: training_1.txt
testing_data: test_1.txt
C = 1
number of test data label: 500
predict corret number of test data label: 500
Success rate: 1.0000

training_data: training_2.txt
testing_data: test_2.txt
C = 1
number of test data label: 500
predict corret number of test data label: 500
Success rate: 1.0000

可以發現測試數據的正確率是百分之百，說明決策邊界剛好可以把正負樣本給完全分隔開。

（3）更改第(1)問中的主函數，其余的代碼不變

• part1_3.m

kertype = 'linear';
gamma = 0;
C = [0.01,0.1,1,10,100];
for i=1:size(C,2)
    predict1('training_1.txt','test_1.txt',kertype,gamma,C(i));
end
for i=1:size(C,2)
    predict1('training_2.txt','test_2.txt',kertype,gamma,C(i));
end

觀察結果

• training_1.txt 和 test_1.txt

C	success rate
0.01	1.0000
0.1	1.0000
1	1.0000
10	1.0000
100	1.0000

• training_2.txt 和 test_2.txt

C	success rate
0.01	1.0000
0.1	1.0000
1	1.0000
10	1.0000
100	1.0000

從上面的結果看似乎沒差別，這是因為我們的數據集太好了，所以預測正確率都是1。正常的情況下，C比較大的時候表示我們想要犯更少的錯誤，但margin會稍微小一點；C比較的小的時候表示我們想要更大的margin，劃分錯誤多一點沒關系。也就是說C比較大時正確率會高一些，而C比較小正確率會低一些。

2. 手寫字體識別

實驗給的strimage.m的作用是從train-01-images.svm中選定指定行以圖片的形式顯示0或1，其中圖片的像素是28×28。
（1）以下兩個m文件處理train-01-images.svm和test-01-images.svm，其功能是參照strimage.m將數據集每一行先轉換為28×28像素的圖像，圖像的每一點有確定的值。然后將所有的點展開成一行全部存儲于hand_digists_train.dat和hand_digists_test.dat。轉換后的hand_digists_train.dat大小為12665×785，hand_digists_test.dat的大小為2115×785，每一行中的最后一個數字對應著標簽，即第785列。

• re_hand_digits.m

function svm = re_hand_digits(filename,n)
  fidin = fopen(filename);
  i = 1;
  apres = [];

while ~feof(fidin)
  tline = fgetl(fidin); % 從文件讀行
  apres{i} = tline;
  i = i+1;
end

 grid = zeros(n,784);
 label = zeros(n,1);
 for k = 1:n
    a = char(apres(k));
    lena = size(a,2);
    xy = sscanf(a(4:lena), '%d:%d');
    label(k,1) = sscanf(a(1:3),'%d');
    lenxy = size(xy,1);
    for i=2:2:lenxy  %% 隔一個數
      if(xy(i)<=0)
          break
      end
      grid(k,xy(i-1)) = xy(i) * 100/255; %轉為有顏色的圖像
    end
 end
  svm.grid = grid;
  svm.label = label;
end

• save_data.m

svm1 = re_hand_digits('train-01-images.svm',12665);
svm2 = re_hand_digits('test-01-images.svm',2115);
train_x = svm1.grid; train_y = svm1.label;
test_x = svm2.grid; test_y = svm2.label;
train = [train_x,train_y];
test = [test_x,test_y];

[row,col] = size(test);
fid=fopen('hand_digits_test.dat','wt');
for i=1:1:row
    for j=1:1:col
        if(j==col)
            fprintf(fid,'%g\n',test(i,j));
        else
            fprintf(fid,'%g\t',test(i,j));
        end
    end
end
fclose(fid);

[row,col] = size(train);
fid=fopen('hand_digits_train.dat','wt');
for i=1:1:row
    for j=1:1:col
        if(j==col)
            fprintf(fid,'%g\n',train(i,j));
        else
            fprintf(fid,'%g\t',train(i,j));
        end
    end
end
fclose(fid);

實驗雖然要求使用全部的訓練集進行訓練，但你會發現使用全部訓練集的時候，使用quadprog函數會出現內存不足的情況，當然好配置的電腦可以跑完，但我們班的大多數人都是跑內存爆炸的，所以這里我只采用大小為3000的訓練集，測試集數量不變，你可以根據自身需求選擇，當然這對實驗的結果是沒多大影響的。

• strimage.m
  實驗雖然給了strimage.m，但我們還是有必要更改一下這個代碼，因為這個代碼只能查看訓練集的0或1的圖像，也就是train-01-images.svm中的圖像，我們的目的是它也能查看test-01-images.svm的0或1圖像，這個代碼其實就加了一個參數filename而已。

function strimage(filename,n)
  fidin = fopen(filename);
  i = 1;
  apres = [];

while ~feof(fidin)
  tline = fgetl(fidin); % 從文件讀行
  apres{i} = tline;
  i = i+1;
end
  %選中我們選定的第n張圖片
  a = char(apres(n));

  lena = size(a);
  lena = lena(2);
  %xy存儲像素的索引和相應的灰度值
  xy = sscanf(a(4:lena), '%d:%d');

  lenxy = size(xy);
  lenxy = lenxy(1);


  grid = [];
  grid(784) = 0;  %28*28網格，0代表黑色背景
  for i=2:2:lenxy  %% 隔一個數
      if(xy(i)<=0)
          break
      end
    grid(xy(i-1)) = xy(i) * 100/255; %轉為有顏色的圖像
  end

  %顯示手寫數字圖像
  grid1 = reshape(grid,28,28);
  grid1 = fliplr(diag(ones(28,1)))*grid1;
  grid1 = rot90(grid1,3);
  image(grid1);
  hold on;
end

• 預測函數predict2.m

function [test_miss,train_miss] = predict2(train_data_name,test_data_name,kertype,gamma,C)
    %(1)-------------------training data ready-------------------
    train_data = train_data_name;
    n = size(train_data,2);
    train_x = train_data(:,1:n-1);
    train_y = train_data(:,n);

    %(2)-----------------training model-------------------
    %二次規劃用來求解問題，使用quadprog
    n = length(train_y);
    H = (train_y*train_y').*kernel(train_x,train_x,kertype,gamma);
    f = -ones(n,1); %f'為1*n個-1
    A = [];
    b = [];
    Aeq = train_y';
    beq = 0;
    lb = zeros(n,1);
    if C == 0  %無正則項
        ub = [];
    else       %有正則項
        ub = C.*ones(n,1);
    end
    train_a = quadprog(H,f,A,b,Aeq,beq,lb,ub);
    epsilon = 2e-7;
    %找出支持向量
    sv_index = find(abs(train_a)> epsilon);
    Xsv = train_x(sv_index,:);
    Ysv = train_y(sv_index);
    svnum = length(sv_index);
    train_w(1:784,1) = sum(train_a.*train_y.*train_x(:,1:784));
    train_b = sum(Ysv-Xsv*train_w)/svnum;
    train_label = sign(train_x*train_w+train_b);
    train_miss = find(train_label~=train_y);

    %(3)-------------------testing data ready----------------------
    test_data = test_data_name;
    m = size(test_data,2);
    test_x = test_data(:,1:m-1);
    test_y = test_data(:,m);
    test_label = sign(test_x*train_w+train_b);
    test_miss = find(test_label~=test_y);

    %(4)------------------detail -----------------------;
    %print the detail
    fprintf('--------------------------------------------\n');
    fprintf('C = %d\n',C);
    fprintf('number of test data label: %d\n',size(test_data,1));
    fprintf('number of train data label: %d\n',size(train_data,1));
    fprintf('predict corret number of test data label: %d\n',length(find(test_label==test_y)));
    fprintf('predict corret number of train data label: %d\n',length(find(train_label==train_y)));
    fprintf('Success rate of test data: %.4f\n',length(find(test_label==test_y))/size(test_data,1));
    fprintf('Success rate of train data: %.4f\n',length(find(train_label==train_y))/size(train_data,1));
    fprintf('--------------------------------------------\n');
end

• 主函數part2.m

train_data = load('hand_digits_train.dat');
test_data = load('hand_digits_test.dat');
train_len = size(train_data,1); test_len = size(test_data,1);
train_index = randperm(train_len,3000);
test_index = randperm(test_len,2115);
train_select = zeros(3000,785);
test_select = zeros(2115,785);
for i = 1:3000
    train_select(i,:) = train_data(train_index(i),:);
end
for i = 1:2115
    test_select(i,:) = test_data(test_index(i),:);
end

%無正則項
[train_miss_index,test_miss_index] = predict2(train_select,test_select,'linear',0,0);
%查看被錯誤分類的手寫字體
%訓練錯誤手寫字體
for i = 1:length(train_miss_index)
   strimage('train-01-images.svm',i);
   figure;
end
%測試錯誤手寫字體
for i = 1:length(test_miss_index)
   strimage('test-01-images.svm',i);
   if i~=length(test_miss_index)
       figure;
   end
end

• 打印訓練錯誤和測試錯誤

C = 0
number of test data label: 2115
number of train data label: 3000
predict corret number of test data label: 2108
predict corret number of train data label: 2991
Success rate of test data: 0.9967
Success rate of train data: 0.9970

• 附上一張訓練錯誤圖像和測試錯誤圖像(左邊是訓練錯誤圖像，右邊是測試錯誤圖像)

  可以發現，錯誤的和書寫不規范有很大的關系。

（2）這里主要改的代碼是主函數part2.m，其余的不用變。

train_data = load('hand_digits_train.dat');
test_data = load('hand_digits_test.dat');
train_len = size(train_data,1); test_len = size(test_data,1);
train_index = randperm(train_len,3000);
test_index = randperm(test_len,2115);
train_select = zeros(3000,785);
test_select = zeros(2115,785);
for i = 1:3000
    train_select(i,:) = train_data(train_index(i),:);
end
for i = 1:2115
    test_select(i,:) = test_data(test_index(i),:);
end

C = [0.01,0.1,1,10,100];
%有正則項
for i=1:size(C,2)
    predict2(train_select,test_select,'linear',0,C(i));
end

觀察結果如下

• 訓練誤差

C	success rate
0.01	0.9963
0.1	0.9973
1	0.9947
10	0.9993
100	0.9920

• 測試誤差

C	success rate
0.01	0.9939
0.1	0.9957
1	0.9910
10	0.9991
100	0.9960

回答下列問題
(i)從上述結果發現C=100時訓練誤差最大。
(ii)問題(i)中對應的測試誤差為1-0.9960 = 0.0040，在matlab顯示2115個測試數據錯了17個。
(iii)由表中可以看C在10時測試誤差和訓練誤差都很小，所以我推測C=10左右會使得測試誤差很小，當然只是我個人推測。

3. 非線性SVM

• 預測函數predict3.m

function test = predict3(train_name,type,gamma,C)
 %-----------------------training data ready------------------------
    train = train_name;
    [m,n] = size(train);
    train_x = train(:,1:n-1);
    train_y = train(:,n);
    pos = find(train_y == 1);
    neg = find(train_y == -1);
    plot(train_x(pos,1),train_x(pos,2),'k+');
    hold on;
    plot(train_x(neg,1),train_x(neg,2),'bs');
    hold on;

    %-----------------------training model--------------------------
    %二次規劃用來求解問題，使用quadprog
    K = kernel(train_x,train_x,type,gamma);
    H = (train_y*train_y').*K;
    f = -ones(m,1);
    A = [];
    b = [];
    Aeq = train_y';
    beq = 0;
    lb = zeros(m,1);
    if C == 0
        ub = [];
    else
        ub = C*ones(m,1);
    end
    a = quadprog(H,f,A,b,Aeq,beq,lb,ub);
    epsilon = 1e-5;
    %查找支持向量
    sv_index = find(abs(a)> epsilon);
    Xsv = train_x(sv_index,:);
    Ysv = train_y(sv_index);
    svnum = length(sv_index);

    %make classfication predictions over a grid of values
    xplot = linspace(min(train_x(:,1)),max(train_x(:,1)),100)';
    yplot = linspace(min(train_x(:,2)),max(train_x(:,2)),100)';
    [X,Y] = meshgrid(xplot,yplot);
    vals = zeros(size(X));

    %calculate decision value
    train_a = a;
    sum_b = 0;
    for k = 1:svnum
        sum = 0;
        for i = 1:m
            sum = sum + train_a(i,1)*train_y(i,1)*K(i,k);
        end
        sum_b = sum_b + Ysv(k) - sum;
    end
    train_b = sum_b/svnum;
    for i = 1:100
        for j = 1:100
            x_y = [X(i,j),Y(i,j)];
            sum = 0;
            for k = 1:m
                sum = sum + train_a(k,1)*train_y(k,1)*exp(-gamma*norm(train_x(k,:)-x_y)^2);
            end
            vals(i,j) = sum + train_b;
        end
    end

    %plot the SVM boundary
    colormap bone;
    contour(X,Y,vals,[0 0],'LineWidth',2);
    title(['\gamma = ',num2str(gamma)]);
end

• 主函數part3.m

type = 'rbf';
train_name = load('training_3.text');
gamma = [1,10,100,1000];
C = 1;
for i = 1:length(gamma)
   predict3(train_name,type,gamma(i),C);
   if i ~= length(gamma)
       figure;
   end
end

• 實驗結果

  可以發現γ越大，會出現過擬合現象，而γ越小，會出現欠擬合現象。
